IVNR316XD - IVSEC NR316XD NVR 16 CHAN NELS 12MP 16 x POE PORTS 2 BAYS H265 4K HDMI IVS

IVNR316XD - IVSEC NR316XD NVR 16 CHAN NELS 12MP 16 x POE PORTS 2 BAYS H265 4K HDMI IVS

$544.57
$722.30 $544.57
Sale Sold out
Taxes included.
 More payment options

CCTV Storage Calculator https//www.seagate.com/au/en/video-storage-calculator/

NR316XD NVR



Included IVS to match cameras with facial detection Human and car detection. Now with Alarm relays


Maximum Channels 16
Maximum Video Resolution Megapixels 12MP
Examples of Channels at a resolution with FPS 112 Mbps
Video Compression H.264 H.264 H.265 H.265 MJPEG
Video Output Resolution 4K HD-1080p HD-720p 1.3 MP D1 VGA
Image Display 1/4/6/8/9/10/13/14/16
Search Method Continuous Scheduling Event Triggered PIR IVS Motion Perimeter Intrusion Detection Line Crossing Detection Stationary Object Detection Pedestrian Detection Face Detection Cross Counting
Total Storage Potential TB 32
HDD Bays Size Bays x2 Up to 16TB per HDD
Software Device Search/Config Tool Surveillance Client CMS/VMS Mobile app
Protocols TCP HTTP HTTPS DHCP DDNS NTP SMTP PPPOE RTSP UPnP ONVIF P2P QR Code
Language English French Dutch German Italian Polish Portuguese Spanish Thai Turkish Hungarian Simplified Chinese Etc.
Audio Streaming Out
Power Over Ethernet Switch Ports 16 up to 802.3at30w
Power Over Ethernet Yes
Power Supply DC48V/3.750A
Power Consumption 10 W &65288;Without HDD&65289;
Connectors HDD 3.5″ SATA HDD Slot x 2 USB3 Female x1 USB2 Female x 2 Gigabit Ethernet RJ-45 Port x 1 and 16 x PoE ports HDMI and VGA Alarm ports 8 in and 1 out Audio out Power Jack input On off switch
Operating Environment 5ºC to 45ºC 41ºF-113ºF Humidity 20-80 RH
In The Box Printed quick installation guide Mouse Remote control HDD screws Power supply.
Warranty 24 months parts
Dimensions 380 X 320 X 54mm
Weight kg 1.54 kg
